Description:
Technical Parameters:
The latest motherboard program: support RDM function, built-in program: built-in a variety of effects programs, you can achieve a single beam white left and right slow swing, single beam color change left and right slow swing and multiple beam color change left and right slow swing.
Voltage: wide voltage 110V-240V 50-60Hz
Light source: 350W Osram Japan Phoenix Bulb
Total power: 500W
Color: color wheel: 13+1+ colorful rainbow effect + atomization function
Pattern: pattern plate: 13 fixed patterns +1 white light
Focusing: electronic linear high-definition dynamic focusing, using high-density glass optical lens.
Linear dimming curve: 0%-100% linear dimming
Beam angle: 2°
Channels: 16/20 international standard DMX512 channels.
Lens diameter: 150mm
XY motor: three electric drive, powerful, faster, more stable and quieter
Appearance: high temperature resistant die-cast aluminum shell, lightweight, adopting wind direction drainage and temperature intelligent monitoring technology, fast heat dissipation!
Waterproof rating: IP65
Control mode: DMX 512, self-propelled, master-slave machine self-propelled
Prism: 48 prisms (24+16+8) superimposed and rotatable, macro function
Display: LCD display adapts to different installation positions
Horizontal/Vertical: The luminaire with 350 waterproof light can scan 540°horizontally or 270°vertically, which is fast and stable.
The lamp is equipped with an intelligent photoelectric reset correction system, which can automatically recover from accidental misoperation.
original position. In addition, there is a horizontal and vertical locking button, which is more convenient for maintenance and transportation.
cooling system:
Use CFD software to analyze and calculate the heat flow of lamps, design a low-noise heat dissipation system
The fan has excellent driving performance and extremely low noise.
Lamp body size: 37*30*68cm Net weight: 23KG
Packing size: 55*44*68cm Gross weight: 27KG
One air box: 42*37*91cm Weight: 37KG
One flight case two: 92*41*91cm weight: 70kg
No show of weakness, small shape, huge energy, thick beam
The performance of the waterproof beam lamp in terms of optics, structure, appearance, etc. has reached the high standard in the industry. It adopts advanced technology and high-brightness light source, optical technology and rigorous industrial design to ensure the perfect presentation of the lighting design.
